Webhooks

Overview

Webhooks allow Dialer.CX to send real-time event notifications to your external systems via HTTP POST requests. When something happens in the platform — a call ends, an agent logs in, a lead is updated — the system immediately notifies any registered webhook endpoints, enabling real-time integrations without polling.

Supported Events

Event	Triggered When	Typical Use
call.started	A new call is initiated	Log call start in CRM
call.ended	A call completes with disposition	Update CRM with outcome, trigger follow-up workflows
agent.login	An agent logs into the workspace	Track attendance, update staffing dashboards
agent.logout	An agent logs out	Calculate shift duration, trigger EOD reports
agent.pause	An agent enters pause state	Monitor break compliance
agent.resume	An agent returns from pause	Track break duration
lead.updated	A lead record is modified	Sync lead data to external CRM
recording.ready	A recording is available for playback	Trigger transcription in external system
alert.triggered	An alert threshold is breached	Push to PagerDuty, Slack, or monitoring tools

Tip

Start with call.ended — it is the most commonly used webhook event and provides the richest data payload including disposition, duration, agent, and campaign information.

Configuration

Navigate to Admin > Settings > Webhooks to manage webhook endpoints:

1. Click Add Webhook
2. Enter the destination URL (must be an HTTPS endpoint for production use)
3. Select which events to subscribe to (you can subscribe to one or all events)
4. Enable or disable the webhook with a toggle
5. Click Save

You can create multiple webhook endpoints, each subscribing to different events. For example, one endpoint for your CRM (call events only) and another for your monitoring system (alert events only).

Payload Format

Webhooks deliver a JSON payload via HTTP POST with the Content-Type: application/json header:

{
  "event": "call.ended",
  "timestamp": "2026-03-07T15:30:00Z",
  "data": {
    "call_id": "12345",
    "agent": "jsmith",
    "phone_number": "5551234567",
    "duration": 180,
    "disposition": "SALE",
    "campaign": "Q1-Sales"
  }
}

The data object varies by event type. Call events include call metadata, agent events include agent information, and lead events include the changed fields.

Delivery and Reliability

Webhook delivery is designed to be reliable even when your endpoint has temporary issues:

• Retries — failed deliveries are retried 3 times with increasing delays (5s, 30s, 120s)
• Delivery log — all webhook attempts are recorded with HTTP status codes and response bodies
• Signature verification — every request includes an X-Webhook-Signature header containing an HMAC-SHA256 signature for payload authentication
• Timeout — 10-second timeout per delivery attempt to prevent slow endpoints from blocking the queue

Note

To verify webhook authenticity on your receiving end, compute the HMAC-SHA256 of the raw request body using your webhook secret and compare it to the X-Webhook-Signature header value. This prevents spoofed webhook deliveries.

Verifying Signatures

Here is an example of signature verification in Node.js:

const crypto = require('crypto');

function verifyWebhook(body, signature, secret) {
  const computed = crypto
    .createHmac('sha256', secret)
    .update(body)
    .digest('hex');
  return crypto.timingSafeEqual(
    Buffer.from(computed),
    Buffer.from(signature)
  );
}

Use Cases

Use Case	Integration	Events
CRM Sync	Push call data to Salesforce, HubSpot, Zoho, etc.	call.ended, lead.updated
Notifications	Send Slack or Teams messages on events	agent.login, agent.logout, alert.triggered
Analytics	Feed data to your BI platform (Looker, Tableau, etc.)	call.ended, call.started
Automation	Trigger workflows in Zapier or Make	Any event
Monitoring	Alert PagerDuty or Opsgenie on operational issues	alert.triggered
Compliance	Log all call activity to an external audit system	call.started, call.ended, recording.ready

Troubleshooting

Check webhook delivery history at Admin > Settings > Webhooks by clicking on any webhook endpoint to view its delivery log.

Issue	Cause	Solution
No deliveries appearing	Webhook disabled or no matching events	Verify the webhook is enabled and subscribed to the right events
All deliveries failing (HTTP 4xx)	Endpoint rejecting requests	Check endpoint URL, authentication requirements, and firewall rules
Intermittent failures (HTTP 5xx)	Destination server errors	Review your endpoint’s error logs; the retry mechanism handles transient failures
Signature mismatch	Wrong secret or body modification	Ensure you are verifying against the raw request body, not a parsed/re-serialized version

Caution

Webhook endpoints receive sensitive data including phone numbers, agent names, and call outcomes. Always use HTTPS endpoints in production and implement proper authentication on your receiving server. Never log full webhook payloads to unprotected locations.
